Antenna

LTE antenna: 2 internal antennas
WiFi 2.4 GHz antenna: 2 internal antennas

Button

Power on/off button
WPS button
Reset button

Frequency

Supported frequency: B1/3/7/8/20/38/40
Supported frequency:
HSPA+/UMTS band 1/8
EDGE/GPRS/GSM band 3/8
Downlink data rate up to 42 Mbps
Uplink data rate up to 5.76 Mbps

Wireless

IEEE 802.11 b / g / n, 2.4 GHz
2.4 GHz WiFi antenna: 2 indoor antennas
Speed: 300 Mb / s for 2.4 GHz

Interface

LTE air interface:
Standard compliance: 3GPP Release 9 Category 4
Frequency supported:
B1 / 3/7/8/20/38/40
LTE antenna: 2 indoor antennas
Peak data rate:
150 Mb / s * DL in the 20 MHz band
50 Mbps * UL in the 20 MHz band

UMTS Air Interface:
Compliant with standards: DC-HSDPA / HSPA +
Frequency supported:
HSPA + / UMTS 1/8 band
EDGE / GPRS / GSM 3/8 band
Data rate down to 42 Mbps
Data transfer rate up to 5.76 Mbps

Hardware interface:
USB 2.0 high speed network access
One mini SIM (2FF) UICC / USIM card slot
One micro SD card slot up to 32 GB
Buttons:
On/Off button
WPS button
Reset button
LED display:
Power
2G / 3G / 4G network status
WiFi status
SMS status

Data Rate

150 Mbps DL within 20 MHz bandwidth
50 Mbps UL within 20 MHz bandwidth
Downlink data rate up to 42 Mbps
Uplink data rate up to 5.76 Mbps

Network Standard

IEEE 802.11 b / g / n, 2.4 GHz

Encryption

WPA / WPA2 PSK and mixed mode WPA / WPA2

Others

Operating Environment:
Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 5% to 95% (non-condensing)
Storage Environment

Temperature: -30°C to 70°C (-22°F to 158°F)
Humidity: 5% to 95% (non-condensing)

Battery:
Removable li-polymer battery
3.7 V, 2000 mAh
Up to 8 hours operating time
(Depends on network environment)

Power Mode

600 mA max

Dimension

Item dimensions (WxDxH): 110.0 x 63.0 x 15.7 mm (4.33” x 2.48” x 0.62”)

Weight

105 g (0.232 lb.)

Color

Black

Warranty

01 Year
