Type
Desktop Gigabit Ethernet Switch
Port
5x10/100/1000 Gigabit Ethernet RJ45 Ports
Network Standard
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3 Nway auto-negotiation
IEEE 802.3x full-duplex operation and flow control
IEEE 802.3az Energy Efficient Ethernet
Data Transmission Rate
Data transfer rate (half-duplex/full-duplex):
Ethernet: 10/20 Mbps
Fast Ethernet: 100/200 Mbps
Gigabit Ethernet: 1000/2000 Mbps
Memory buffer: 128 KB
Switching fabric (non-blocking): 10 Gbps
MAC Address Table
2 K
Environment
Operating Environment
Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 10% to 90% (Non-condensing)
Storage Environment
Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 10% to 95% (Non-condensing)
Interface
Five RJ-45 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support
LED
LED Indicator
PWR: Power
Per-port: Link/Activity
Amber: 10/100 Mbps
Green: 1000 Mbps
Power Supply
Input: 100-240 V AC
Output: 5 V DC, 1 A
Power consumption: 2.5 watt max.
Dimensions (L x W x H)
(WxDxH): 121 x 75 x 26 mm (4.8" x 3.0" x 1.0")
Weight
229 g (0.50 lb.)
Warranty
01 Year
The GS-105B v3 is suitable for every occasion. Its robust, compact design adds adaptability to wired home networks, regardless of whether it is positioned on a desktop or a wall. The Zyxel GS-105B v3 5-Port Desktop Gigabit Switch connects devices and the home network at Gigabit speeds and may be used in any environment. The Zyxel GS-105B v3 5-Port Desktop Gigabit Switch can boost data transfer speeds to Gigabit for connected network devices such as IP phones, network storage devices, PCs, and laptops.
