Processor

CPU Model: Intel Xeon D-1527
CPU Quantity: 1
CPU Architecture: 64-bit
CPU Frequency: 4-core 2.2 (base) / 2.7 (turbo) GHz

Memory

System Memory: 8 GB DDR4 ECC UDIMM
Memory Module Pre-installed: 8 GB (8 GB x 1)
Total Memory Slots: 4
Maximum Memory Capacity: 64 GB (16 GB x 4)

Hard Disk

3.5" SATA HDD: HAT5300
2.5" SATA SSD: SAT5210

Network

25GbE Network Interface Card: E25G21-F2
10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1

Mount

4-post 19" rack (Synology Rail Kit - RKM114/RKS-02)

Power Supply and Cable

150 W
AC Input Power Voltage: 100V to 240V AC
Power Frequency: 50/60 Hz, Single Phase
Power Consumption: 68.68 W (Access)
34.78 W (HDD Hibernation)

Drive Bays

2 (NVMe & SATA)

Form Factor

1U

Others

Maximum Drive Bays with Expansion Unit: 16 (RX1217/RX1217RP x 1)
RJ-45 1GbE LAN Port: 4 (with Link Aggregation / Failover support)
USB 3.2 Gen 1 Port*: 2
Expansion Port: 1
PCIe Expansion: 1 x Gen3 x8 slot (x8 link)
Internal Drives: Btrfs, EXT4
External Drives: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT
Size (Height x Width x Depth): 44 mm x 480 mm x 518.6 mm
Weight: 8.16 kg
System Fan: 40 mm x 40 mm x 2 pcs
Fan Speed Mode: Full-Speed Mode, Cool Mode, Quiet Mode
Operating Temperature: 5°C to 35°C (40°F to 95°F)
Storage Temperature: -20°C to 60°C (-5°F to 140°F)
Relative Humidity: 5% to 95% RH

Warranty

5 Years Warranty
