Processor Brand
AMD
Processor Model
Ryzen 7 7745HX
Processor Frequency
3.6GHz to 5.1GHz
Processor Core
8
Processor Thread
16
CPU Cache
L1 Cache: 512KB
L2 Cache: 8MB
L3 Cache: 32MB
Chipset Model
AMD SoC Platform
Display Size
16-inch
Display Type
IPS
Display Resolution
WQXGA (2560x1600)
Refresh Rate
240Hz
Display Features
500nits Anti-glare
100% sRGB
DisplayHDR 400
Dolby Vision
G-SYNC
Low Blue Light
High Gaming Performance
RAM
16GB (2x 8GB)
RAM Type
DDR5
Removable
Yes
Bus Speed
5200MHz
Total RAM Slot
2
Storage Type
M.2 2280 PCIe 4.0x4 NVMe
Storage Capacity
1TB
Extra M.2 Slot
Yes
Supported SSD Type
M.2 2280 PCIe 4.0 x4
Storage Upgrade
Up to 1TB M.2 2280 SSD
Graphics Model
NVIDIA GeForce RTX 4070
Graphics Memory
8GB
Graphics Type
GDDR6
Keyboard Type
Backlit Keyboard
Keyboard Features
4-Zone RGB Backlit
TouchPad
Yes
WebCam
FHD 1080p
Speaker
2W x2, Stereo speakers
Microphone
2x Array Microphone
Audio Features
High Definition (HD) Audio Chip
Realtek ALC3306 codec
Nahimic Gaming Audio
HDMI Port
1x HDMI 2.1, up to 8K/60Hz
USB 3 Port
1x USB 3.2 Gen 1 (Always On)
3x USB 3.2 Gen 1
USB Type-C / Thunderbolt Port
1x USB-C 3.2 Gen 2 (support data transfer and DisplayPort 1.4)
1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 140W and DisplayPort 1.4)
Headphone & Microphone Port
1x Headphone / microphone combo jack (3.5mm)
LAN
100/1000M (RJ-45)
WiFi
Wi-Fi 6E, 11ax 2x2
Bluetooth
Bluetooth V5.2
Camera Privacy Shutter
E-shutter
Security Chip
Firmware TPM 2.0
Operating System
Windows 11 Home
Battery Type
Integrated
Battery Capacity
80Wh
Adapter Type
300W Slim Tip (3-pin)
Color
Onyx Grey
Weight
Less than 2.5 kg (5.5 lbs)
Dimensions
363.4 x 260.35 x 22.45-26.75 mm (14.31 x 10.25 x 0.88-1.05 inches)
Body Material
Aluminum (Top), PC-ABS (Bottom)
Warranty Details
2 Years Warranty (Battery & Adapter 1 Year)
The new Lenovo Legion Pro 5 16ARX8 Ryzen 7 7745HX RTX 4070 8GB Graphics 16" 240Hz Gaming Laptop is a top-tier gaming laptop designed for serious gamers. It is powered by an AMD Ryzen 7 7745HX processor, which has eight cores, sixteen threads, and three different CPU cache sizes: L1 (512KB), L2 (8MB), and L3 (32MB). A vibrant and clear visual experience is offered by the laptop's 16-inch WQXGA (2560x1600) IPS display, which has a refresh rate of 240Hz, 500nits of anti-glare, 100% sRGB, DisplayHDR 400, Dolby Vision, G-SYNC, Low Blue Light, and High Gaming Performance. It has a 1TB M.2 2280 PCIe 4.0x4 NVMe SSD for storage and 16GB (2x 8GB) DDR5 RAM with a bus speed of 5200MHz, so you can play games and run apps with ease. With 8GB of GDDR6 memory, the laptop's NVIDIA GeForce RTX 4070 graphics card provides exceptional graphics performance. It is powered by the Windows 11 Home operating system, which offers a feature-rich interface. The laptop's integrated 80Wh battery ensures long-lasting operation. Its 4-Zone RGB Backlit backlit keyboard makes typing comfortable even in dimly lit environments. A Full HD 1080p webcam, 2W x 2 stereo speakers, 2x Array Microphone, High Definition (HD) Audio Chip, Realtek ALC3306 codec, Nahimic Gaming Audio, one HDMI 2.1 port supporting up to 8K/60Hz, one USB 3.2 Gen 1 (Always On) port, three USB 3.2 Gen 1 ports, two USB-C 3.2 Gen 2 ports (supporting DisplayPort 1.4 and data transfer), and one 3.5mm headphone / microphone combo jack are also features of the laptop. The laptop is lightweight and portable, measuring less than 2.5 kg and measuring 363.4 x 260.35 x 22.45–26.75 mm. Its Onyx Grey hue lends a sense of refinement to the design.
