IP Camera Input

Up to 64-ch 12 MP IP cameras can be connected

Two-Way Talk

1-ch, RCA (2.0 Vp-p, 1 k Ω)

Interface

H.265+/H.265/H.264/H.264+/MPEG4

Decoding Capacity

2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps)

Resolution

CVBS output (Optional) : 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
VGA1 /HDMI1 output resolution : HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 ×
VGA2 /HDMI2 output resolution : 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Record Rate

128 Mbps

Alarm Input

Yes

Sync Playback

Yes ( 8-ch )

Playback Function

12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF /2CIF/CIF/QCIF

Third Party Support

YesH.265+/H.265/H.264/H.264+/MPEG4

Interface

2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

Ethernet Port

2

Network Function

TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS

HDD Mode

8 SATA interfaces for 8HDDs
Up to 10TB capacity for each HDD

eSATA

1 eSATA interface

USB

Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0

RS232

Yes

RS485

Yes

Power Supply

100 to 240 VAC, 50 to 60 Hz

Power Consumption

Max. Power : 200 W
Consumption (without HDD) : ≤ 30 W

Dimensions

445 × 470 ×90 mm (17.5"× 18.5" × 3.5")

Net Weight

Weight (without HDD) : ≤ 8 kg (17.6 lb)
