IP Camera Input

IP video input: 16-ch

Two-Way Talk

Two-way audio: 1-ch, RCA (2.0 Vp-p, 1kΩ)

Resolution

4K (3840 x 2160) resolution

HDMI output resolution: 4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/60Hz, 1920 x 1080/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz

VGA output resolution: 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz

Record Rate

Up to 8 Megapixels resolution recording

Video Detection

IP video input: 16-ch
Support H.265/H.264/MPEG4 video formats

Alarm Input

Support various VCA detection alarm and VCA search
Alarm in/out: 16/4

Sync Playback

16-ch

Search Mode

Yes

Playback Function

Yes

Backup Mode

Yes

Third Party Support

Third-party network cameras supported

Interface

4 SATA interfaces for 4HDDs
Network interface: 2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces
USB interfaceFront panel: 2 x USB 2.0; Rear panel: 1 x USB 3.0
Serial interface: 1 RS-485 (half-duplex), 1 RS-232, 1 keyboard (optional)

Ethernet Port

2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces

Network Function

Third-party network cameras supported
16/32-ch network cameras can be connected with 160M/256M incoming bandwidth
Incoming bandwidth: 160 Mbps
Outgoing bandwidth: 160 Mbps
Remote connection: 128

Internal HDD

SATA: 4 SATA interfaces for 4HDDs
Capacity: Up to 6TB capacity for each HDD

HDD Mode

4 SATA interfaces

USB

Front panel: 2 x USB 2.0;
Rear panel: 1 x USB 3.0

Power Supply

100 to 240 VAC

Power Consumption

Consumption(without hard disk and POE): ≤20 W

Dimensions

445 x 390 x70 mm ( 17.5"x 15.3" x 2.8")

Net Weight

Weight (without hard disk): ≤ 5 kg (11 lb)
