Casing

Inner core: Metal + Plastic
Cover: Plastic
Decoration ring: Plastic
Pedestal: Plastic

Dimensions

85.5 mm × Φ109 mm (3.4" × Φ4.3")

Weight

Net Weight: 0.24 kg (0.5 lb)
Gross Weight: 0.37 kg (0.8 lb)

Pan/Tilt/Rotation

Pan: 0° to 355°
Tilt: 0° to 78°
Rotation: 0° to 360°

Operating Conditions

-40°C to +60°C (-40°F to +140°F)/less than ≤ 95%

Storage Conditions

-40°C to +60°C (-40°F to +140°F)

Power Supply

12 V / PoE (802.3af)

Power Consumption

Basic power consumption: 1.4W (12V DC); 2.2W (PoE)
Max. power consumption (ICR + H.265+IR intensity): 3.3W (12V DC); 4.3W (PoE)

Image Sensor

1/2.8" CMOS

Effective Pixels

2MP

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s

Minimum Illumination

0.01 Lux @F2.0

S/N Ratio

>65dB

IR Distance

25 m (82.0 ft)
Illumination Distance: 30 m (98.4 ft)
Smart Illumination

IR LEDs

1

Lens Type

Fixed -Focal

Mount Type

M12

Focal Length

2.8mm; 3.6mm

Max Aperture

2.8 mm: F2.0
3.6 mm: F2.0

Angle of View

2.8 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120°
3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100°

Focus Control

Iris Control: Fixed

Close Focus Distance

2.8 mm: 0.5 m (1.6 ft)
3.6 mm: 0.8 m (2.6 ft)

Resolution

1080p (1920 × 1080); 1.3M(1280 × 960);720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Frame Rate

Main Stream: 1920 × 1080 (1 fps–25/30 fps)
Sub stream: 704 × 576 (1 fps–25 fps), 704 × 480 (1 fps–30 fps)

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Day/Night

Auto (ICR)/Color/B/W

BLC Mode

Yes

Gain Control

Auto/Manual

Noise Reduction

3D NR

Features

Region of Interest (RoI): Yes (4 areas)
Smart Illumination: Yes
Image Rotation: 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
Mirror: Yes
Privacy Masking: 4 areas
Alarm: Alarm Event
Network disconnection; IP conflict; illegal access; motion detection; video tampering; safety exception
Network: RJ-45 (10/100 Base-T)
SDK and API: Yes
Cyber Security: Video encryption;configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
Network Protocol: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast
Interoperability: ONVIF (Profile S/Profile T); CGI; P2P; Genetec
User/Host: 6 (Total bandwidth: 36 M)
Storage: FTP
Browser: IE
Chrome: Firefox
Management Software: Smart PSS; DSS; DMSS
Mobile Client: IOS; Android
Certification: CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
Bit Rate Control: CBR/VBR
Stream Capability: 2 streams
Video Compression: H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
Smart Codec: Smart H.265+/Smart H.264+
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100000 s
Min. Illumination: 0.01 Lux @F2.0
S/N Ratio: >56 dB
Illumination Distance: 30 m (98.4 ft)
Illuminator On/Off Control: Auto
ROM: 16 MB
RAM: 64 MB

Warranty

1 Year Warranty
