Type

Unmanaged PoE Switch

Port

8 x 10/100/1000 (PoE+)

Network Standard

IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3 Nway auto-negotiation
IEEE 802.3x full-duplex operation and flow control
IEEE 802.3az Energy Efficient Ethernet

Data Transmission Rate

Data transfer rate (half-duplex/full-duplex):
Ethernet: 10/20 Mbps
Fast Ethernet: 100/200 Mbps
Gigabit Ethernet: 1000/2000 Mbps

MAC Address Table

4 K

Environment

Operating Environment
-Temperature: 0°C to 40°C (32°F to 104°F)
-Humidity: 10% to 90% (Non-condensing)
Storage Environment
-Temperature: -40°C to 70°C (-40°F to 158°F)
-Humidity: 10% to 90% (Non-condensing)

Interface

8 RJ-45 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support

LED

LED Indicator

PWR: Power
PoE MAX:
Amber: PoE power output over 50W (total budget 60W)
Per port: Link/Activity
Amber: 10/100 Mbps
Green: 1000 Mbps
Per port : PoE+
Green: PoE supported

Power Supply

AC-to-DC external power adapter
Input: 100-240 V AC
Output: 55V DC/1.3A

Dimensions (L x W x H)

(WxDxH): 240 x 105 x 26 mm (9.45"x4.13"1.02")

Weight

610g ( 1.34 lb.)

Warranty

01 Year
